WAYTRAIN UE331DSAE
Machine Subcategory
Semi-Automatic Horizontal Bandsaw
Overview
Semi-Automatic bandsaw with two way mitre up to 60 degrees. Variable blade speed, Hydraulic Vices and Powered Bow raise all as standard.
Standard Specification
- Heavy duty bow, cast guide arms with carbide pads for fast accurate cutting
- Easy mitre 60° - 0 - 60°
- Full stoke hydraulic vice with vice pressure reduction
- Automatic head height setting
- Infinitely variable blade speed 32 – 96m/min
- Blade speed readout
- Variable downfeed control
- Swivelling control box
- Motor driven chip brush
Get in touch +44 (0)1536 410999
WAYTRAIN UE331DSAE Technical Specifications
| Manufacturer | Waytrain |
|---|---|
| Machine Type | Bandsaw |
| Blade Size | 4180mm × 34mm × 1.1mm |
| Blade Speed | Variable speed - 26~80m/min |
| Motor | 2.2kW |
| Hydraulic Tank | 12 litres |
| Coolant Tank | 52 litres |
| Weight | 850 |
| Material Type(s) | Section |
| Material(s) | Sections |
| 90° | 45° Left | 45° Right | 60° Left | 60° Right | |
|---|---|---|---|---|---|
| Round Section (mm) | 331mm | 315mm | 215mm | ||
| Rectangular Section Horizontal (mm) | 510x260mm | 315x195mm | |||
| Rectangular Section Vertical (mm) | 485x320mm | ||||
| Square Section (mm) | 315x315mm |
