WAYTRAIN WL800SAT
Machine Subcategory
Semi-Automatic Horizontal Bandsaw
Overview
This Waytrain machine is a heavy duty bandsaw with a hydraulic moving table for positioning material and cutting capacity of 800mm for sawing of large capacity solid bar.
Standard Specification
- Double clamping vise
- Power driven wire brush
- Human-machine interface control panel
- Hydraulic blade tension
- Hydraulic automatic chip conveyor
- Hydraulic blade guide arm movement
- Hydraulic carbide blade guide
- Hydraulic table movement for feeding of material
- Broken blade detection sensor
- Full stroke hydraulic vises
- Split vise clamping
- Linear guides on saw-bow movement
- Inverter control blade speed
Optional Features
- Delivery to your works (unloading not included
- Conveyors & magazine feed systems
- Commissioning and operator instruction (see terms)
- Vice pressure reduction
- Bundle Clamp
- Blade deflection monitor
- Laser line
- Blades & Service contracts
WAYTRAIN WL800SAT Technical Specifications
| Manufacturer | Waytrain |
|---|---|
| Blade Size | 8300mm × 54mm × 1.6mm |
| Blade Speed | Invertor variable speed 20~85m/min |
| Table Height | 620mm |
| Motor | 7.5kW |
| Motor | 2.2kW |
| Hydraulic Tank | 90 litres |
| Coolant Motor | 0.2kW |
| Coolant Tank | 160 litres |
| Weight | 7300 |
| Capacity Solid 90 Round | 800mm | ||||
| Capacity Solid 90 Square | 800x800mm | ||||
