Single Cylinder Steelworker
Exclusive and UNIQUE from Geka, the GEKA Bendicrop 50 is a single cylinder 50 tonne steelworker with 6 workstations. This hydraulic ironworker machine is fitted with a bending station and a system to avoid distortions when cutting plates.
Thanks to the blade holder's vertical movement, the machine has an excellent performance in all its SIX work stations:
Punching
Notching
Shear for flat bars
Angle cutting
Cutting of round and square bars
+ Bending as standard
Fitted with an anti torque system to reduce deformation when shearing flat bars.
The BENDICROP model is fitted with a touch and cut length stop and is delivered with two V-shaped bending dies of 40mm and 70mm width.
Permanently fitted bending station complying with CE standards.
Goose neck die-holder for punching of angle and channel sections on flanges and web.
Quick tool change
Angle shearing without loss of material.
Flat bar and plate shearing system with minimum deformation & mitre shearing up to 45º.
Rectangular (OR triangular) notching with table.
| Manufacturer | GEKA |
| Machine Type | Steel Worker |
| Steel Flatbarshear | 350 x 10mm, 350 x 15mm (5º) |
| Punching | 31 through 12mm |
| Steel Rectangular Notching | 90 x 42 x 10mm |
| Steel Triangular Notching | 100 x 100 x 10mm |
| Steel Angle Shear 90 | 80 x 80 x 8mm |
| Steel Solid Bar | 35mm round, 30mm square |
| Punching Power | 500kN |
| Tonnage | 50 tonnes |
| Throat Capacity | 177mm |
| Table Height | 973mm |
| Motor | 3kW |
| Weight | 1000 kgs net |
